Harnessflex,CIH08-BC2 Interface, , CIH08-BC2

Harnessflex, CIH08-BC2 Interface

Brand: Harnessflex SKU: CIH08-BC2
TempGuard External Hinged Connector Interface for Bosch Compact

Single junction straight fittings providing high integrity, high temperature connection between Bosch Compact connectors and Harnessflex conduit systems in elevated temperature areas. Full TempGuard system protection is achieved using these fittings with HTC conduit.

Min Temp: -40ºC
Max Temp: 160ºC

Please Note All product images are for illustration purposes only. Actual product will vary depending on the specifications of the product selected.

TempGuard External Hinged Connector Interface for Bosch Compact

Single junction straight fittings providing high integrity, high temperature connection between Bosch Compact connectors and Harnessflex conduit systems in elevated temperature areas. Full TempGuard system protection is achieved using these fittings with HTC conduit.

Temperature Range

Minimum   -40ºC
Permanent Max    160ºC
Long term max (30,000 hrs)    185ºC
Short term max (3,000 hrs)    200ºC

Features
  • One-piece external design for unrestricted bore and quick assembly with no tools.
  • High pull-off strength – conduit corrugations sit tightly into joiner junctions.
  • Conduit size labels – each junction indicates nominal conduit size to aid installation
  • High Temperature Polyamide (Nylon) – Low Smoke & Halogen Free
  • IP40 rated
  • High UV resistance
Conformity
  • CE Mark to the low voltage directive
  • RoHS Compliant to 2011/65/EU
  • Conforms with end of life vehicle directive (ELV) EU200/53/EC
  • UL94 V2 / UL94 RTI 150 (Elec)
Harnessflex
CIH08-BC2

Data sheet

Connector
1 928 403 137
Minimum Temperature
-40ºC
Maximum Temperature
160ºC
Long Term Max Temp
185ºC
Short Term Max Temp
200ºC
Long Term Max Time
30000 hours
Short Term Max Time
3000 hours
New product
