Harnessflex,PP08 Medium Weight Conduit – 100m, , PP08

Harnessflex, PP08 Medium Weight Conduit – 100m

Brand: Harnessflex SKU: PP08
Polypropylene conduit, Modified Polypropylene

PP is particularly used in lighter applications where compression strength and LFH is not as important. The main property of this conduit is acid resistance. PP is designed for connection to all Harnessflex Sealed and Hinged system fittings.

Min Temp: -60ºC
Max Temp: 260ºC

Please Note All product images are for illustration purposes only. Actual product will vary depending on the specifications of the product selected.

Polypropylene conduit, Modified Polypropylene

PP is particularly used in lighter applications where compression strength and LFH is not as important. The main property of this conduit is acid resistance. PP is designed for connection to all Harnessflex Sealed and Hinged system fittings.

Features
  • High flexibility and acid resistance
  • Medium fatigue life, impact and shock resistance
  • Temperature range: -20ºC to 90ºC
    Temperature range short-term: 105°C
  • UV Resistance – High
  • IP40 – IP67 (depending on fittings)
  • Halogen free
Conformity
  • CE Mark to the low voltage directive
  • RoHS Compliant to 2011/65/EU
  • Conforms with end of life vehicle directive (ELV)EU200/53/EC
  • UL94 HB
Harnessflex
PP08

Data sheet

Minimum Temperature
-60ºC
Maximum Temperature
260ºC
Short Term Max Temp
300ºC
